You'll find more facts on the Norwegian page. Especially the "Turbeskrivelser" section on the left hand side. Norwegian only, text-wise, but also a lot of inspiring pics... smile

Designer: Rolf Magnusson
Built at Contrast Marine, Christinehamn, Sweden 1981/82


Overall length: 9.85 m
Waterline: 8,30 m
Beam: 3,05 m
Draft: 1,65 m
Displacement: 4200 kg
Keel weight: 1700 kg lead
Engine: Freshwater-cooled (Martec kit) 2 cyl 17,5 Hp Volvo Penta diesel MD7B with 120S-drive. (replaced 2011)
Folding propeller
5/6 rig

Sail area:
Main: 25,0 m2
Genoa 1: 32,0 m2
Genoa 2: 26,0 m2
Genoa 3: 18,5 m2
Jib: 19,0 m2
Spinnaker 1: 82,0 m2
Spinnaker 2: 68,0 m2
LYS: 1,16

Tanks:
Water: 65 l (+ 20 l in water heater)
Fuel: 35 l
Septic: 55 l
